Disassembly of the bottom half of a mass-production G1G1 XO-1. Top (relative to how you see it when you remove it) view of the keyboard/touchpad controller board. This side faces down when the XO is fully assembled. CN5 connects to the keyboard, CN2 and CN3 are for the touchpad. CN1 goes to the motherboard.
