This is a waveform trace from a XO-1.5 B3 prototype laptop (after modification.)
The channels are:
- Yellow - VA18 (+1.8V to WLAN), controlled by WLAN_PW
- Cyan - MAIN_ON (SUSC#)
- Green - WLAN_PW (gate drive, generated by a high voltage inverter from WLAN_EN#)
- Magenta - Q38, pin 2 (filtered version of SDIO1_PWOFF/WLAN_EN#)
